300x300mm column vertical section view
Description
300x300mm column vertical section view is given in this AutoCAD drawing model. 50mm blinding concrete, reinforcement details, Expansion joint, waterproofing membrane, isolation joint, grade beam, and polyethylene are specified. For more details download the AutoCAD drawing file from our website.
